Modular Server Rooms & IT Buildings
Adacon designs and manufactures secure modular buildings for server rooms, IT infrastructure, communications equipment and edge-computing installations. We build the insulated modular enclosure around the project's equipment, access, cooling, electrical and security requirements, working alongside your IT, M&E and specialist infrastructure contractors. The same building suits an external server room, an IT or network equipment room, a communications or telecom room, an edge-computing enclosure or a small data-centre shell.
Get a price for server rooms & it buildings
The more we know about the equipment and services, the faster we can size the building around them. Upload drawings or schedules if you have them.
Hire Server Rooms & IT Buildings in the UK
Need server rooms & it buildings for a fixed period? Hire it instead of buying. Adacon manufactures the building to your layout and hands it over on hire terms, then collects it when you no longer need it — with the same quality, fit-out and design freedom as a purchase.
Hire terms are flexible — tell us how long you need the unit and we will confirm the rate for that period.
Get a hire price for server rooms & it buildings
Tell us when you need it and for how long. We reply with hire terms — and a purchase price too if you tick compare.
The building around your technology
We start from what your IT and M&E designers need the building to do: the equipment layout, heat load, power and data routes, access for installation and maintenance, and the security of an unattended site. The enclosure is then sized and specified around those requirements.
- Internal size set from rack and equipment layouts and maintenance clearances
- Cable entry positions and containment routes agreed with your IT designer
- Openings and provisions for cooling equipment positioned to your specification
- Power provisions and distribution planned with your electrical engineer
- Secure doors, locks and controlled openings for unmanned sites
- Provisions for fire detection and suppression systems, installed by your specialist
- Floor loading reviewed against rack and equipment weights
- Insulated, weathertight envelope with robust external cladding
Example configurations
Buildings combine P300, P400, P500, P600 and P700 units, with bespoke options. A separate P600 provides approximately 11.4 m² usable internally. Example areas use a conservative per-module allowance before partitions; open joins can provide more space. Units can be combined or stacked over two storeys.
A compact external server room or comms room for a business site, school or surgery.
A larger IT building with separate equipment, UPS and working zones.
Server room joined to an office, store or welfare space for an attended site.
Server Rooms & IT Buildings — key facts
- P300 unit
- 2.9m × 2.2m externally; approximately 2.7m × 2.0m usable internally (5.4 m² usable internal area per separate unit)
- P400 unit
- 3.9m × 2.2m externally; approximately 3.7m × 2.0m usable internally (7.4 m² usable internal area per separate unit)
- P500 unit
- 4.9m × 2.2m externally; approximately 4.7m × 2.0m usable internally (9.4 m² usable internal area per separate unit)
- P600 unit
- 5.9m × 2.2m externally; approximately 5.7m × 2.0m usable internally (11.4 m² usable internal area per separate unit)
- P700 unit
- 6.9m × 2.2m externally; approximately 6.7m × 2.0m usable internally (13.4 m² usable internal area per separate unit)
- Configuration
- Mix P300, P400, P500, P600 and P700 units to create tailored footprints and shapes
- Bespoke
- Bespoke sizes considered to suit your brief — contact us
- Joined internal space
- Open joins remove the adjoining shell walls and can increase usable space. Final clear area depends on layout and partitions.
- Unit height
- 2.40m external / 2.16m internal
- Storeys
- Up to two storeys, subject to final project design
- Delivery
- UK mainland and Northern Ireland — transport quoted separately
Adacon modular buildings use P300, P400, P500, P600 and P700 units with external lengths of 2.9m, 3.9m, 4.9m, 5.9m and 6.9m, a common 2.2m width and 2.40m external / 2.16m internal height. The sizes can be combined to create more tailored floor areas and building shapes, joined side by side or stacked to two storeys subject to the final project design.
What's available for a server rooms & it building
Adacon designs and manufactures the modular building only. Racks, servers, cooling systems, UPS, power architecture, fire suppression, networking and resilience design are specified, supplied and commissioned by your IT, M&E and specialist infrastructure contractors. Fire, security, cooling and structural requirements are confirmed per project against their specification.
Server Rooms & IT Buildings — photo gallery
Tell us what the building needs to house
Share your equipment layout and your engineers' requirements — we'll size and specify the enclosure around them.
Server Rooms & IT Buildings — common questions
Related uses
Modular control rooms, monitoring rooms, site offices and welfare buildings for battery storage, solar and wind sites. Specialist electrical specification confirmed per project.
Modular and prefabricated plant room buildings made around your equipment and engineering specification — for heating, pumps, water systems, electrical equipment, controls and generators.
Modular amenity buildings for EV charging hubs and electric forecourts — waiting lounge, coffee and retail, accessible WC, staff and security rooms. Repeatable across sites.
Modular security cabins with all-round visibility, secure locking, heating and power. Built for construction sites, industrial premises and car parks.
Design options for this build
All design optionsLiving in one of these?
All modular homesUseful guides
Modular buildings need a level, load-bearing base rather than traditional deep foundations. Learn what base types suit garden rooms, site offices and two-storey builds.
Yes. P600 modules can be fitted with tea points, canteen kitchens or commercial servery kitchens, with plumbing, extraction and power installed in the factory.
How kitchens, shower rooms and WCs are designed into a garden annexe or garden room, and what it means for services and planning.
Built from five unit sizes, or bespoke
Every Adacon building is made from these units, or built to a bespoke size. Units can be combined — joined end to end, side by side, or stacked to two storeys — to create larger buildings.
| Unit | External footprint | Approximate usable internal area |
|---|---|---|
| P300 | 2.9m × 2.2m | 2.7m × 2.0m (≈5.4 m²) |
| P400 | 3.9m × 2.2m | 3.7m × 2.0m (≈7.4 m²) |
| P500 | 4.9m × 2.2m | 4.7m × 2.0m (≈9.4 m²) |
| P600 | 5.9m × 2.2m | 5.7m × 2.0m (≈11.4 m²) |
| P700 | 6.9m × 2.2m | 6.7m × 2.0m (≈13.4 m²) |
| Bespoke | Built to your size | Contact us |
