    Modular House Extensions
    1 module·approx. 11.4 m² internal
    Modular Homes

    Modular House Extensions

    Where a traditional extension means months of building work against the house, a modular extension is manufactured off site and installed in a fraction of the time — single-storey or as stacked two-storey modules, linked to the house or as a detached building in the garden.

    Extra space without living on a building site

    The decision is usually whether to link the new space to the house or keep it detached. Detached is simpler — no structural opening, no party-wall complications — and is often what people actually need when they want a bedroom, office or living room.

    • Detached garden building, or a linked structure alongside the house
    • Bedroom, office, living room or gym layouts
    • Shower room or WC where drainage allows
    • Cladding matched or contrasted with the existing house
    • Short site programme — base, craneage and connections
    • Relocatable if you move or reconfigure the garden

    Two-storey modular extensions

    A two-storey prefab extension stacks matching modules so the new space sits on two floors over a smaller footprint. It is a different purchase from a two-storey modular home: a home is a standalone building, whereas an extension has to work with an existing property — its structure, roof line, drainage, access and any connecting opening. Adacon manufactures and installs the stacked modules; the connection to your house is designed and delivered by your project team.

    • Matching modules stacked with ground-floor and first-floor rooms, e.g. living space below and a bedroom with shower room above
    • Internal stairs where floor area allows, or external stairs to keep both floors open
    • Foundations designed for the stacked load and your ground conditions, and the structure reviewed for every two-storey project
    • Any structural opening into the house, flashing to the existing wall and party-wall matters handled by your builder or engineer
    • Planning permission and Building Regulations confirmed for your site — two-storey extensions rarely fall under permitted development
    • Crane access to lift each module into place, checked before ordering
    • Price set by the number of modules and the fit-out you choose in the designer, plus the separately quoted site works and transport

    Example configurations

    Combine P300, P400, P500, P600 and P700 units to tailor room sizes and footprints. Matching units can also stack over two storeys.

    1 module
    approx. 11.4 m² internal

    A single extra room — office, bedroom or snug.

    2 modules
    approx. 22.8 m² usable

    Living space with a shower room, or two separate rooms.

    4 modules
    approx. 45.6 m² usable

    A full annexe-scale extension with bedroom, bathroom and living area.

    2 modules over 2 storeys
    approx. 22.8 m² usable

    Two-storey extension: one room downstairs, one room upstairs, on a single-module footprint.

    4 modules over 2 storeys
    approx. 45.6 m² usable

    Two-storey extension: living and kitchen below, bedroom and shower room above.

    Modular House Extensions — key facts

    P200 unit
    1.9m × 2.2m externally; approximately 1.7m × 2.0m usable internally (3.4 m² usable internal area per separate unit)
    P300 unit
    2.9m × 2.2m externally; approximately 2.7m × 2.0m usable internally (5.4 m² usable internal area per separate unit)
    P400 unit
    3.9m × 2.2m externally; approximately 3.7m × 2.0m usable internally (7.4 m² usable internal area per separate unit)
    P500 unit
    4.9m × 2.2m externally; approximately 4.7m × 2.0m usable internally (9.4 m² usable internal area per separate unit)
    P600 unit
    5.9m × 2.2m externally; approximately 5.7m × 2.0m usable internally (11.4 m² usable internal area per separate unit)
    P700 unit
    6.9m × 2.2m externally; approximately 6.7m × 2.0m usable internally (13.4 m² usable internal area per separate unit)
    Configuration
    Mix P200, P300, P400, P500, P600 and P700 units to create tailored footprints and shapes
    Bespoke
    Bespoke sizes considered to suit your brief — contact us
    Joined internal space
    Open joins remove the adjoining shell walls and can increase usable space. Final clear area depends on layout and partitions.
    Unit height
    2.40m external / 2.16m internal
    Storeys
    Up to two storeys, subject to final project design
    Delivery
    UK mainland and Northern Ireland — transport quoted separately

    Adacon modular buildings use P200, P300, P400, P500, P600 and P700 units with external lengths of 1.9m, 2.9m, 3.9m, 4.9m, 5.9m and 6.9m, a common 2.2m width and 2.40m external / 2.16m internal height. The sizes can be combined to create more tailored floor areas and building shapes, joined side by side or stacked to two storeys subject to the final project design.

    What's available

    Bedrooms and internal partitionsShower room and WCKitchen or kitchenetteInsulated walls, floor and roofDouble-glazed windows and doorsFull-height glazingHeating provisionLED lighting and power socketsTerrace, decking or balconyPer-wall cladding style and colour

    Modular House Extensions — photo gallery

    Guest & Garden Accommodation
    Guest & Garden Accommodation
    One Bedroom Modular Homes
    One Bedroom Modular Homes
    Two Bedroom Modular Homes
    Two Bedroom Modular Homes
    Three Bedroom Modular Homes
    Three Bedroom Modular Homes
    Modular Bungalows
    Modular Bungalows
    Two-Storey Modular Homes
    Two-Storey Modular Homes
    Garden Annexes & Granny Flats
    Garden Annexes & Granny Flats
    Tiny Homes
    Tiny Homes
    Modular Holiday Homes
    Modular Holiday Homes

    Whether a building can be used as a permanent dwelling, and what Building Regulations, planning permission, foundations and energy-performance requirements apply, depends entirely on your site and how the building will be used. We make no blanket claim that a standard configuration constitutes a compliant dwelling — this must be confirmed for your specific project.

    Modular House Extensions — common questions

    Design your extension

    Choose the size, rooms and cladding and get an estimated price.

    Get a price for Modular House Extensions

    Tell us what you need and we'll come back with pricing and lead times — usually within one working day.

    So we can call you back about your enquiry

    Enquiring about: Modular House Extensions

    No obligation. We reply within one working day.
