Modular Clubhouses
3-Module Two-Storey Modular Clubhouse
This three-module P600 modular clubhouse combines two ground-floor modules with a first-floor module, roof terrace and external staircase. It is configured for sports clubs and community organisations seeking a compact two-storey facility.
£40,860ex VAT
£49,032 inc VAT · indicative configured estimate, subject to quotation. Transport depends on postcode and access; offloading, groundworks and site-specific works are separate.
Made to order. Build and delivery timing will be confirmed with your quotation.
Order the standard specification online. We'll confirm delivery, access and final order details before accepting your order and issuing your invoice.
Built to order in approx. 7–8 weeks, then delivery typically within 1–2 weeks. Delivery is priced by postcode and confirmed with your quote.
- Modules
- 3
- Storeys
- 2
- Approx. usable internal area
- 34.2 m² before partitions
- External dimensions
- 5.9m x 4.4m footprint
Design highlights
- Three 5.9m x 2.2m P600 modules
- Two-storey 5.9m x 4.4m external footprint
- Approx. 34.2m² usable internal area before partitions
- Roof terrace with balustrade above one ground module
- External steel staircase
- Pure White RAL 9010 smooth insulated exterior panels
- Requested kitchenette, WC and shower fit-out
Clubhouse configuration
This steel-framed building is configured as a modular clubhouse for the Sport & Leisure sector. It uses three P600 modules, each measuring 5.9m x 2.2m, arranged over two storeys within a 5.9m x 4.4m external footprint.
The configuration provides approximately 34.2m² of usable internal area before partitions, based on a conservative per-module allowance. Connected open layouts may provide more space. Each module is 2.40m high externally, with a 2.16m internal ceiling and an approximate usable interior of 5.7m x 2.0m.
Two-storey layout and terrace
Modules 1 and 2 sit alongside one another at ground-floor level. Module 3 is positioned on the first floor above one ground module, while the roof terrace with balustrade occupies the area above the other. An external steel staircase runs up the outside of the building.
The upper structure has a dual-pitch apex roof. The combination of enclosed accommodation and an elevated terrace is suited to clubhouse layouts where internal facilities and an outdoor viewing or social area are required within a compact footprint.
Configured windows and doors
- Module 1: two large windows and a pair of glazed doors on the north side, plus one large window on each of the east and west ends.
- Module 2: one large window on each of the east and west ends. Its south side has a large central window with one small window on either side.
- Module 3: two large windows on the north side; two small windows on each end; and two large windows with a single glazed door on the south side.
External and internal finishes
The selected exposed walls use included vertical insulated sandwich panels in Pure White, RAL 9010, with a smooth finish. This specification applies to the configured north, east, south and west exterior walls shown in the stored design. Alternative cladding costs are confirmed by quotation and are not itemised here.
A kitchenette, WC and shower have been requested, with their positions and details to be confirmed in the final room configuration. Bathroom walls use 40mm waterproof insulated sandwich panels as standard, with hygienic panels available as an option. Shower rooms use wet-room PVC flooring. Where selected, plaster applies outside bathroom walls.
Elsewhere, insulated sandwich panels are the included wall finish. Any other internal wall or floor finishes depend on the final room layout and quotation, so illustrated fixtures, finishes and room arrangements should not be treated as guaranteed inclusions.
Price and site considerations
The indicative configured estimate is £40,860 excluding VAT, or £49,032 including VAT, subject to quotation. Transport is priced separately according to the delivery postcode and site access. Offloading or cranage, groundworks and other site-specific works are also separate.
Placement and access requirements remain subject to a site survey. The survey and quotation will account for the proposed position, access constraints and any site works needed for this exact three-module, two-storey arrangement.
Full specification
3 P600 modules (two storeys), two-storey-terrace layout, 5.9m x 4.4m footprint, approx 34.2 m2 usable internal area before partitions (conservative per-module allowance; connected open layouts may provide more space). Each module is 2.40m externally with a 2.16m internal ceiling; its approximate usable interior is 5.7m x 2.0m. Exterior: included vertical insulated sandwich panels in Pure White (RAL 9010). Roof: dual-pitch (apex) roof. Selected outside walls: Module 1 North wall: Standard insulated panel, Pure White (RAL 9010), Smooth; Module 1 East wall: Standard insulated panel, Pure White (RAL 9010), Smooth; Module 1 West wall: Standard insulated panel, Pure White (RAL 9010), Smooth; Module 2 East wall: Standard insulated panel, Pure White (RAL 9010), Smooth; Module 2 South wall: Standard insulated panel, Pure White (RAL 9010), Smooth; Module 2 West wall: Standard insulated panel, Pure White (RAL 9010), Smooth; Module 3 North wall: Standard insulated panel, Pure White (RAL 9010), Smooth; Module 3 East wall: Standard insulated panel, Pure White (RAL 9010), Smooth; Module 3 South wall: Standard insulated panel, Pure White (RAL 9010), Smooth; Module 3 West wall: Standard insulated panel, Pure White (RAL 9010), Smooth. Cladding prices are quote-only and must not be itemised in public copy. Module 1 P600 (ground floor) exposed walls — north (5.9m side): Large window + Glazed door (double) + Large window; east (2.2m end): Large window; west (2.2m end): Large window. Module 2 P600 (ground floor) exposed walls — east (2.2m end): Large window; south (5.9m side): Small window + Large window + Small window; west (2.2m end): Large window. Module 3 P600 (first floor) exposed walls — north (5.9m side): Large window + Large window; east (2.2m end): Small window + Small window; south (5.9m side): Large window + Glazed door (single) + Large window; west (2.2m end): Small window + Small window. Roof terrace with balustrade above 1 ground module(s). External steel staircase up the outside of the building. Requested fit-out to confirm in the final layout: kitchenette, WC, shower. Bathroom walls use 40mm waterproof insulated sandwich panels as standard, with hygienic panels optional; shower rooms use wet-room PVC flooring. Plaster applies outside bathroom walls when selected. Elsewhere insulated sandwich panels are the included wall finish; other finishes are selected for the final room layout.
