Modular Shower Blocks
Single-Module Shower Block with WC
This single-storey P600 modular shower block combines a requested WC and shower within an approximately 11 m² usable interior. It is suited to construction sites, campsites and sports clubs requiring compact washroom facilities.
£12,900ex VAT
£15,480 inc VAT · indicative configured estimate, subject to quotation. Transport depends on postcode and access; offloading, groundworks and site-specific works are separate.
Made to order. Build and delivery timing will be confirmed with your quotation.
Order the standard specification online. We'll confirm delivery, access and final order details before accepting your order and issuing your invoice.
Built to order in approx. 7–8 weeks, then delivery typically within 1–2 weeks. Delivery is priced by postcode and confirmed with your quote.
- Modules
- 1
- Storeys
- 1
- Floor area
- 11 m²
- Footprint
- 5.9m x 2.2m footprint
Design highlights
- One 5.9m x 2.2m P600 module
- Approximately 11 m² usable internal area
- Requested WC and shower fit-out
- Glazed double door with two small windows
- Three high-level top-only windows
- Smooth Pure White RAL 9010 external panels
- Flat roof with approximately 120mm fascia
Compact single-module configuration
This modular shower block uses one P600 steel-framed module arranged over a single storey. Its external footprint is 5.9m x 2.2m, with an approximate internal usable floor area of 11 m². The usable interior measures approximately 5.7m x 2.0m, providing a compact format for construction sites, campsites and sports clubs where dedicated WC and shower facilities are required.
The module is 2.40m high externally and has a 2.16m internal ceiling. This stored configuration is based on one module and one layout, rather than a multi-module or stacked arrangement. Further information about this type of building is available on the modular shower blocks page.
Doors and windows
The north-facing 5.9m wall has one high-level, top-only window. The east-facing 2.2m end and west-facing 2.2m end each have a high-level, top-only window. The south-facing 5.9m wall contains a small window, a glazed double door and a second small window. These openings form part of this specific stored design and should be reviewed alongside the final internal arrangement.
External finish and roof
All four outside walls use standard insulated sandwich panels in Pure White, RAL 9010. The selected panels have a smooth finish and are installed vertically across the north, east, south and west elevations. The module has a flat roof with an approximately 120mm steel-frame fascia. No additional fascia has been selected for this configuration.
Requested washroom fit-out
A WC and shower are requested for the fit-out, with their exact positioning and room arrangement to be confirmed in the final layout. Toilet and shower areas require hygienic wall panels and wet-room PVC flooring to provide suitable internal surfaces for these spaces. The final quotation will confirm the agreed fixtures, room divisions, finishes and associated fit-out details rather than relying on illustrated examples.
Internal wall and floor choices
Away from the toilet and shower areas, the included internal wall finish is white, lightly ribbed insulated sandwich panelling. Plasterboard and alternative hygienic-panel styles are selectable choices or upgrades and are not included in this stored specification. No room-by-room flooring selection has been confirmed outside the required wet-room PVC flooring for the toilet and shower areas.
- One P600 module over a single storey
- Approximately 11 m² of usable internal floor area
- Requested WC and shower fit-out
- High-level windows on three elevations
- Glazed double door with two small windows on the south wall
- Pure White smooth insulated external panels
Estimate, transport and siting
The indicative configured estimate is £12,900 excluding VAT, or £15,480 including VAT, subject to quotation and confirmation of the final layout and fit-out. Transport is priced separately according to the delivery postcode and site access. Offloading or cranage, groundworks and other site-specific works are also separate. Siting requirements, access and ground conditions remain subject to survey. Configuration details can be reviewed through the building configurator.
Full specification
1 P600 module (single storey), single layout, 5.9m x 2.2m footprint, approx 11 m2 internal usable floor area. Each module is 2.40m externally with a 2.16m internal ceiling; its approximate usable interior is 5.7m x 2.0m. Exterior: included vertical insulated sandwich panels in Pure White (RAL 9010). Roof: flat roof with approximately 120mm steel-frame fascia (no extra fascia). Selected outside walls: Module 1 North wall: Standard insulated panel, Pure White (RAL 9010), Smooth; Module 1 East wall: Standard insulated panel, Pure White (RAL 9010), Smooth; Module 1 South wall: Standard insulated panel, Pure White (RAL 9010), Smooth; Module 1 West wall: Standard insulated panel, Pure White (RAL 9010), Smooth. Cladding prices are quote-only and must not be itemised in public copy. Module 1 P600 (ground floor) exposed walls — north (5.9m side): Top-only window (high level); east (2.2m end): Top-only window (high level); south (5.9m side): Small window + Glazed door (double) + Small window; west (2.2m end): Top-only window (high level). Requested fit-out to confirm in the final layout: WC, shower. Toilet/shower rooms require hygienic wall panels and wet-room PVC flooring; elsewhere white lightly ribbed insulated sandwich panels are the included wall finish. Plasterboard, other hygienic-panel styles and room-by-room flooring are selectable upgrades/choices, not included claims unless specified.
Frequently asked questions
Make it yours
Change the module count, layout, windows, doors and finish — then get an instant estimate.
Get a price for Single-Module Shower Block with WC
Tell us what you need and we'll come back with pricing and lead times — usually within one working day.
