Six-module, single-storey dark grey classroom with a glazed double door and multiple windows, Adacon P600 modular building — Six-module L-shaped P600 modular classroom for primary and secondary school capacity expansion.

Modular Classrooms

6-Module L-Shaped Classroom with Kitchenette and WC

This six-module P600 building provides an L-shaped, single-storey modular classroom with approximately 73 m² of internal floor area. It suits primary and secondary schools that need additional teaching capacity with an integrated kitchenette and WC.

£72,000ex VAT

£86,400 inc VAT · standard fitted specification. Delivery, groundworks and site-specific works quoted separately.

Configure this design Request a quote

Modules: 6
Storeys: 1
Floor area: 73 m²
Footprint: 17.7m x 8.1m footprint

What's included

Six P600 modules in a single-storey L-shaped layout
17.7m x 8.1m overall footprint
Approximately 73 m² internal floor area
Vertical dark grey exterior cladding
Dual-pitch apex roof
Glazed double entrance door with multiple large and full-size windows
Standard fitted specification with kitchenette and WC

A practical L-shaped teaching space

This configuration uses six P600 steel-framed modules to create a single-storey building with an L-shaped layout. Its overall footprint is 17.7m x 8.1m, providing approximately 73 m² of internal floor area. It is designed for primary and secondary schools expanding capacity and can support general teaching, group learning or other education-led uses.

The L-shape gives the building a clear external form while allowing windows on several elevations. Each P600 module measures 5.9m x 2.2m and is linked to form one fitted building. Further information on this type of education space is available on the modular classrooms page.

Module-by-module layout

Module 1 has two large windows and a double glazed door along its exposed north-facing 5.9m side. A full-size window is fitted to the exposed west-facing 2.2m end.
Module 2 has two large windows along its exposed north-facing 5.9m side, bringing natural light into this section of the classroom.
Module 3 has two large windows on its north-facing 5.9m side and two more on its exposed south-facing 5.9m side. Its east-facing 2.2m end has a full-size window.
Module 4 has two large windows along its exposed west-facing 5.9m side. A full-size window is also fitted to the exposed south-facing 2.2m end.
Module 5 has a full-size window in its exposed south-facing 2.2m end.
Module 6 has two large windows along its exposed east-facing 5.9m side, plus a full-size window in the south-facing 2.2m end.

The glazed double door in Module 1 provides the external entrance. The specified mix of large and full-size windows serves every exposed section listed in the configuration, helping distribute daylight around the L-shaped plan without adding openings that are not required.

Exterior and internal fit-out

The exterior is finished in vertical dark grey cladding and topped by a dual-pitch apex roof. This gives the classroom a defined pitched-roof profile rather than the flat roofline commonly associated with temporary accommodation.

Internally, the standard fitted specification includes a kitchenette and WC. These facilities allow the building to operate as a self-contained education space, subject to the required site utility connections. Adacon designs, manufactures and delivers P600 buildings, with installation available at school sites across the UK.

Price and programme

The indicative price for this six-module classroom is £72,000 excluding VAT, or £86,400 including VAT, based on the standard fitted specification described here. The price covers the configured building with its stated exterior finish, doors, windows, kitchenette and WC. Delivery, groundworks and all other site-specific works are quoted separately once the location and installation requirements are known.

A typical lead time is 8–12 weeks. The final programme depends on design confirmation, site information, access arrangements and readiness for delivery. Buyers can review alternative arrangements using the P600 configurator, although changes to this exact specification may affect both price and lead time.

Preparing the school site

The site must be prepared for the building before delivery. Requirements include suitable groundworks for local conditions, clear access for module delivery and lifting, and planned connections for the kitchenette and WC. Available working space, site boundaries and access through an occupied school must also be assessed. These items are reviewed and priced separately because they vary between locations.

Full specification

6 P600 modules (single storey), l-shape layout, 17.7m x 8.1m footprint, approx 73 m2 internal floor area.
Exterior: vertical cladding in Dark grey. Roof: dual-pitch (apex) roof.
Module 1 (ground floor) exposed walls — north (5.9m side): Large window + Glazed door (double) + Large window; west (2.2m end): Full-size window.
Module 2 (ground floor) exposed walls — north (5.9m side): Large window + Large window.
Module 3 (ground floor) exposed walls — north (5.9m side): Large window + Large window; east (2.2m end): Full-size window; south (5.9m side): Large window + Large window.
Module 4 (ground floor) exposed walls — south (2.2m end): Full-size window; west (5.9m side): Large window + Large window.
Module 5 (ground floor) exposed walls — south (2.2m end): Full-size window.
Module 6 (ground floor) exposed walls — east (5.9m side): Large window + Large window; south (2.2m end): Full-size window.
Internal fit-out includes: kitchenette, WC.
