3-Module Two-Storey Site Welfare Unit
This three-module P600 site welfare unit provides two storeys within a compact 5.9m x 4.4m external footprint. It suits construction sites seeking space for canteen and drying-room functions, with WC and shower facilities requested for final layout confirmation.
£41,500ex VAT
£49,800 inc VAT · indicative configured estimate, subject to quotation. Transport depends on postcode and access; offloading, groundworks and site-specific works are separate.
Made to order. Build and delivery timing will be confirmed with your quotation.
Order the standard specification online. We'll confirm delivery, access and final order details before accepting your order and issuing your invoice.
Built to order in approx. 7–8 weeks, then delivery typically within 1–2 weeks. Delivery is priced by postcode and confirmed with your quote.
- Modules
- 3
- Storeys
- 2
- Approx. usable internal area
- 34.2 m² before partitions
- External dimensions
- 5.9m x 4.4m footprint
Design highlights
- Three 5.9m x 2.2m P600 modules over two storeys
- Approximately 34.2 m2 usable internal area before partitions
- Compact 5.9m x 4.4m external footprint
- Internal staircase connecting the two floors
- Anthracite vertical ARLINE AR16016 grooved plank cladding
- Glazed double entrance door with small and high-level windows
- Kitchenette, WC and shower requested for final layout confirmation
Three-module layout and usable space
This P600 configuration combines three steel-framed modules in a two-storey arrangement. Two 5.9m x 2.2m modules form the ground floor, with the third module positioned at first-floor level. An internal staircase connects the floors and is not visible externally. The complete building occupies an external footprint of 5.9m x 4.4m.
The configuration provides approximately 34.2 m2 of usable internal area before partitions, based on a conservative per-module allowance. Each module has an approximate usable interior of 5.7m x 2.0m, a 2.40m external height and a 2.16m internal ceiling. Connected open layouts may provide more usable space, depending on the final partition plan.
Windows, entrance and external finish
Module 1 is on the ground floor. Its exposed north-facing 5.9m wall has a glazed double door positioned between two small windows. The east and west 2.2m ends each have one high-level, top-only window.
Ground-floor Module 2 has two high-level, top-only windows on its exposed south-facing 5.9m wall. Its east and west 2.2m ends each have a further high-level, top-only window. Together, the ground-floor openings support the proposed welfare layout while retaining high-level glazing around the shorter ends.
First-floor Module 3 has three small windows on both its north and south 5.9m walls. Its east and west 2.2m ends each have two small windows. The exact relationship between these openings and the internal rooms will be confirmed through the final layout.
All selected exposed walls are finished with Anthracite ARLINE AR16016 grooved plank cladding, applied between the steel frame with the boards arranged vertically. The building has a flat roof and an approximately 120mm steel-frame fascia, with no additional fascia specified.
Requested welfare fit-out
The requested fit-out comprises a kitchenette, WC and shower, subject to confirmation in the final room layout. This allows the accommodation to be planned for typical construction-sector welfare needs, including canteen, drying-room and WC functions. Further information on this use is available under site welfare units.
Insulated sandwich panels are the included wall finish outside the bathroom specification. Bathroom walls use 40mm waterproof insulated sandwich panels as standard, with hygienic panels available as an option. Shower rooms use wet-room PVC flooring. Where selected, plaster applies outside bathroom walls; other finishes are chosen to suit the confirmed room arrangement.
Estimate, transport and siting
The indicative configured estimate is £41,500 ex VAT (£49,800 inc VAT), subject to quotation. Transport is priced according to postcode and site access. Offloading or cranage, groundworks and site-specific works are separate. Configuration details and final selections can be reviewed through the building configurator.
Siting remains subject to survey, including access, ground conditions and the requirements of the selected location. The quotation will confirm the final layout, fixtures, finishes, transport requirements and any site-specific provisions.
Full specification
3 P600 modules (two storeys), two-storey layout, 5.9m x 4.4m footprint, approx 34.2 m2 usable internal area before partitions (conservative per-module allowance; connected open layouts may provide more space). Each module is 2.40m externally with a 2.16m internal ceiling; its approximate usable interior is 5.7m x 2.0m. Exterior: ARLINE AR16016 grooved plank applied to exposed walls between the frame in Anthracite. Roof: flat roof with approximately 120mm steel-frame fascia (no extra fascia). Selected outside walls: Module 1 North wall: Full-wall cladding, Anthracite, ARLINE AR16016 grooved plank, vertical boards; Module 1 East wall: Full-wall cladding, Anthracite, ARLINE AR16016 grooved plank, vertical boards; Module 1 West wall: Full-wall cladding, Anthracite, ARLINE AR16016 grooved plank, vertical boards; Module 2 East wall: Full-wall cladding, Anthracite, ARLINE AR16016 grooved plank, vertical boards; Module 2 South wall: Full-wall cladding, Anthracite, ARLINE AR16016 grooved plank, vertical boards; Module 2 West wall: Full-wall cladding, Anthracite, ARLINE AR16016 grooved plank, vertical boards; Module 3 North wall: Full-wall cladding, Anthracite, ARLINE AR16016 grooved plank, vertical boards; Module 3 East wall: Full-wall cladding, Anthracite, ARLINE AR16016 grooved plank, vertical boards; Module 3 South wall: Full-wall cladding, Anthracite, ARLINE AR16016 grooved plank, vertical boards; Module 3 West wall: Full-wall cladding, Anthracite, ARLINE AR16016 grooved plank, vertical boards. Cladding prices are quote-only and must not be itemised in public copy. Module 1 P600 (ground floor) exposed walls — north (5.9m side): Small window + Glazed door (double) + Small window; east (2.2m end): Top-only window (high level); west (2.2m end): Top-only window (high level). Module 2 P600 (ground floor) exposed walls — east (2.2m end): Top-only window (high level); south (5.9m side): Top-only window (high level) + Top-only window (high level); west (2.2m end): Top-only window (high level). Module 3 P600 (first floor) exposed walls — north (5.9m side): Small window + Small window + Small window; east (2.2m end): Small window + Small window; south (5.9m side): Small window + Small window + Small window; west (2.2m end): Small window + Small window. Internal staircase between the two floors (not visible outside). Requested fit-out to confirm in the final layout: kitchenette, WC, shower. Bathroom walls use 40mm waterproof insulated sandwich panels as standard, with hygienic panels optional; shower rooms use wet-room PVC flooring. Plaster applies outside bathroom walls when selected. Elsewhere insulated sandwich panels are the included wall finish; other finishes are selected for the final room layout.
