Site Welfare Units
3-Module Site Welfare Unit with WC and Shower
This two-storey site welfare unit combines three P600 modules in a 5.9m x 4.4m external footprint. It suits construction sites requiring space for canteen, drying room and WC facilities, with a shower and WC requested for the final layout.
£38,700ex VAT
£46,440 inc VAT · indicative configured estimate, subject to quotation. Transport depends on postcode and access; offloading, groundworks and site-specific works are separate.
Made to order. Build and delivery timing will be confirmed with your quotation.
Order the standard specification online. We'll confirm delivery, access and final order details before accepting your order and issuing your invoice.
Built to order in approx. 7–8 weeks, then delivery typically within 1–2 weeks. Delivery is priced by postcode and confirmed with your quote.
- Modules
- 3
- Storeys
- 2
- Approx. usable internal area
- 34.2 m² before partitions
- External dimensions
- 5.9m x 4.4m footprint
Design highlights
- Three 5.9m x 2.2m P600 modules
- Two-storey 5.9m x 4.4m external footprint
- Approx. 34.2m² usable internal area before partitions
- Internal staircase between ground and first floors
- Single glazed entrance door and specified window arrangement
- Smooth Cream RAL 9001 insulated external panels
- WC and shower fit-out requested for final layout
Three-module, two-storey arrangement
This configuration uses three 5.9m x 2.2m steel-framed P600 modules. Two linked modules form the ground floor, creating the 5.9m x 4.4m external footprint, while the third module forms the first floor. An internal staircase connects the two levels and is not visible from outside. The completed configuration provides approximately 34.2m² of usable internal area before partitions, based on a conservative per-module allowance. Connected open layouts may provide more usable space.
Each module is approximately 2.40m high externally and has a 2.16m internal ceiling. Its approximate usable interior is 5.7m x 2.0m. Final partition positions will depend on the confirmed arrangement of welfare spaces, circulation, WC and shower facilities.
Windows and entrance
On the ground floor, Module 1 has two small windows and one single glazed door on its exposed north wall. Its exposed east and west ends each have two small windows. Module 2 has two small windows on both its exposed east and west ends. Its exposed south wall has two high-level, top-only windows, providing openings suitable for a room where additional privacy may be required.
The first-floor Module 3 has three small windows on its north wall and three on its south wall. Its east and west ends each have two small windows. These are the stored openings for this configuration; final fixture and finish details remain subject to the quotation.
Selected exterior specification
The included exterior uses vertically installed insulated sandwich panels in Cream, RAL 9001. The selected exposed outside walls use standard insulated panels with a smooth Cream finish: the north, east and west walls of Module 1; the east, south and west walls of Module 2; and all four outside walls of Module 3. The building has a flat roof with an approximately 120mm steel-frame fascia and no additional fascia.
Requested welfare fit-out
A WC and shower are requested, with their positions and room arrangement to be confirmed in the final layout. Bathroom walls use 40mm waterproof insulated sandwich panels as standard, while hygienic panels are optional. Shower rooms use wet-room PVC flooring. Where selected, plaster applies outside the bathroom walls. Elsewhere, insulated sandwich panels are the included internal wall finish, with any alternative finishes selected to suit the final room layout.
Construction site use
This configuration is intended as a site welfare unit for the construction sector. Its two-storey format can support sites needing canteen, drying room and WC facilities while limiting the external footprint. The precise allocation of those spaces is not fixed in the stored design and should be agreed alongside the requested WC and shower when the layout is finalised through the building configurator.
Pricing, transport and siting
The indicative configured estimate is £38,700 excluding VAT, or £46,440 including VAT, subject to quotation. Transport is priced separately according to the delivery postcode and site access. Offloading or cranage, groundworks and other site-specific works are also separate. Siting is subject to survey, including confirmation of access, ground conditions and the requirements of the selected location.
Full specification
3 P600 modules (two storeys), two-storey layout, 5.9m x 4.4m footprint, approx 34.2 m2 usable internal area before partitions (conservative per-module allowance; connected open layouts may provide more space). Each module is 2.40m externally with a 2.16m internal ceiling; its approximate usable interior is 5.7m x 2.0m. Exterior: included vertical insulated sandwich panels in Cream (RAL 9001). Roof: flat roof with approximately 120mm steel-frame fascia (no extra fascia). Selected outside walls: Module 1 North wall: Standard insulated panel, Cream (RAL 9001), Smooth; Module 1 East wall: Standard insulated panel, Cream (RAL 9001), Smooth; Module 1 West wall: Standard insulated panel, Cream (RAL 9001), Smooth; Module 2 East wall: Standard insulated panel, Cream (RAL 9001), Smooth; Module 2 South wall: Standard insulated panel, Cream (RAL 9001), Smooth; Module 2 West wall: Standard insulated panel, Cream (RAL 9001), Smooth; Module 3 North wall: Standard insulated panel, Cream (RAL 9001), Smooth; Module 3 East wall: Standard insulated panel, Cream (RAL 9001), Smooth; Module 3 South wall: Standard insulated panel, Cream (RAL 9001), Smooth; Module 3 West wall: Standard insulated panel, Cream (RAL 9001), Smooth. Cladding prices are quote-only and must not be itemised in public copy. Module 1 P600 (ground floor) exposed walls — north (5.9m side): Small window + Glazed door (single) + Small window; east (2.2m end): Small window + Small window; west (2.2m end): Small window + Small window. Module 2 P600 (ground floor) exposed walls — east (2.2m end): Small window + Small window; south (5.9m side): Top-only window (high level) + Top-only window (high level); west (2.2m end): Small window + Small window. Module 3 P600 (first floor) exposed walls — north (5.9m side): Small window + Small window + Small window; east (2.2m end): Small window + Small window; south (5.9m side): Small window + Small window + Small window; west (2.2m end): Small window + Small window. Internal staircase between the two floors (not visible outside). Requested fit-out to confirm in the final layout: WC, shower. Bathroom walls use 40mm waterproof insulated sandwich panels as standard, with hygienic panels optional; shower rooms use wet-room PVC flooring. Plaster applies outside bathroom walls when selected. Elsewhere insulated sandwich panels are the included wall finish; other finishes are selected for the final room layout.
Frequently asked questions
Make it yours
Change the module count, layout, windows, doors and finish — then get an instant estimate.
Get a price for 3-Module Site Welfare Unit with WC and Shower
Tell us what you need and we'll come back with pricing and lead times — usually within one working day.
