Single-Module Modular Toilet Block
This single-storey P600 modular toilet block uses one 5.9m x 2.2m module with a requested WC fit-out. It suits construction sites, events and sports grounds requiring permanent WC provision.
£14,100ex VAT
£16,920 inc VAT · indicative configured estimate, subject to quotation. Transport depends on postcode and access; offloading, groundworks and site-specific works are separate.
Made to order. Build and delivery timing will be confirmed with your quotation.
Order the standard specification online. We'll confirm delivery, access and final order details before accepting your order and issuing your invoice.
Built to order in approx. 7–8 weeks, then delivery typically within 1–2 weeks. Delivery is priced by postcode and confirmed with your quote.
- Modules
- 1
- Storeys
- 1
- Approx. usable internal area
- 11.4 m² before partitions
- External dimensions
- 5.9m x 2.2m footprint
Design highlights
- One 5.9m x 2.2m P600 module
- Approximately 11.4m² usable internal area before partitions
- Single-storey layout with requested WC fit-out
- Anthracite vertical ARLINE AR16016 grooved plank cladding
- Four high-level top-only windows and two small windows
- Single glazed entrance door
- Flat roof with approximately 120mm steel-frame fascia
Single-module layout
This configuration uses one P600 steel-framed module arranged as a wide, single-storey modular toilet block. Its external footprint is 5.9m x 2.2m, with an external module height of 2.40m and an internal ceiling height of 2.16m. The approximate usable interior measures 5.7m x 2.0m, providing approximately 11.4m² of usable internal area before partitions. This is a conservative per-module allowance for planning the requested WC arrangement.
Designed for the Construction sector, the unit is suited to sites, events and sports grounds that need permanent WC provision in a compact standalone format. Further information on this type of building is available in our modular toilet blocks overview.
Windows and access
The north 5.9m wall has two high-level, top-only windows. The east 2.2m end and west 2.2m end each have one high-level, top-only window. On the south 5.9m wall, the stored design includes a single glazed door positioned between two small windows. These selected openings bring controlled natural light into the interior while retaining a practical arrangement for the proposed sanitary use.
Anthracite external finish
All four exposed walls are finished between the steel frame with Anthracite ARLINE AR16016 grooved plank cladding. The boards are arranged vertically across the north, east, south and west elevations, creating a consistent appearance around the complete module. The design has a flat roof with an approximately 120mm steel-frame fascia and no additional fascia.
Requested WC fit-out
A WC is requested for the final internal layout and remains subject to confirmation in the quotation. Bathroom walls use 40mm waterproof insulated sandwich panels as standard, while hygienic panels are available as an optional selection. Where plaster is selected, it applies outside the bathroom walls. Elsewhere in the module, insulated sandwich panels are the included internal wall finish, with any alternative finishes determined alongside the final room arrangement.
Wet-room PVC flooring applies to shower rooms. A shower room is not specified in this stored configuration, so this flooring would only be relevant if the final quoted layout introduced that room type. Fixtures, finishes and partition positions shown during design development are not guaranteed until confirmed in the quotation. The stored arrangement can be reviewed through the building configurator.
Siting and commercial basis
The indicative configured estimate is £14,100 excluding VAT, or £16,920 including VAT, and is subject to quotation. Transport is priced separately according to the delivery postcode and site access. Offloading or cranage, groundworks and other site-specific works are also separate from this estimate.
Siting remains subject to a survey of the proposed location, including access and the conditions relevant to positioning the module. The final quotation confirms the room layout, selected finishes, fixtures and project-specific requirements. Cladding costs are incorporated into the configured estimate and are not itemised publicly.
Full specification
1 P600 module (single storey), wide layout, 5.9m x 2.2m footprint, approx 11.4 m2 usable internal area before partitions (conservative per-module allowance; connected open layouts may provide more space). Each module is 2.40m externally with a 2.16m internal ceiling; its approximate usable interior is 5.7m x 2.0m. Exterior: ARLINE AR16016 grooved plank applied to exposed walls between the frame in Anthracite. Roof: flat roof with approximately 120mm steel-frame fascia (no extra fascia). Selected outside walls: Module 1 North wall: Full-wall cladding, Anthracite, ARLINE AR16016 grooved plank, vertical boards; Module 1 East wall: Full-wall cladding, Anthracite, ARLINE AR16016 grooved plank, vertical boards; Module 1 South wall: Full-wall cladding, Anthracite, ARLINE AR16016 grooved plank, vertical boards; Module 1 West wall: Full-wall cladding, Anthracite, ARLINE AR16016 grooved plank, vertical boards. Cladding prices are quote-only and must not be itemised in public copy. Module 1 P600 (ground floor) exposed walls — north (5.9m side): Top-only window (high level) + Top-only window (high level); east (2.2m end): Top-only window (high level); south (5.9m side): Small window + Glazed door (single) + Small window; west (2.2m end): Top-only window (high level). Requested fit-out to confirm in the final layout: WC. Bathroom walls use 40mm waterproof insulated sandwich panels as standard, with hygienic panels optional; shower rooms use wet-room PVC flooring. Plaster applies outside bathroom walls when selected. Elsewhere insulated sandwich panels are the included wall finish; other finishes are selected for the final room layout.
