Toilet & Shower Blocks
4-Module Toilet and Shower Block
This single-storey toilet and shower block combines four P600 modules to provide approximately 46 m² of usable internal space. It is configured for holiday parks, campsites and large construction sites requiring a wide-format welfare facility.
£54,000ex VAT
£64,800 inc VAT · indicative configured estimate, subject to quotation. Transport depends on postcode and access; offloading, groundworks and site-specific works are separate.
Made to order. Build and delivery timing will be confirmed with your quotation.
Order the standard specification online. We'll confirm delivery, access and final order details before accepting your order and issuing your invoice.
Built to order in approx. 7–8 weeks, then delivery typically within 1–2 weeks. Delivery is priced by postcode and confirmed with your quote.
- Modules
- 4
- Storeys
- 1
- Floor area
- 46 m²
- Footprint
- 5.9m x 8.8m footprint
Design highlights
- Four linked P600 modules in a single-storey layout
- 5.9m x 8.8m footprint
- Approximately 46 m² of usable internal floor area
- Single glazed entrance door with small windows
- High-level top-only windows across exposed walls
- Anthracite AR16016 smooth plank cladding
- Requested WC and shower fit-out
Wide four-module configuration
This toilet and shower block is formed from four linked P600 steel-framed modules arranged as a single-storey, wide-format building. The completed configuration has a footprint of 5.9m x 8.8m and provides approximately 46 m² of usable internal floor area.
Each module measures 5.9m x 2.2m, with an external height of 2.40m and an internal ceiling height of 2.16m. The approximate usable interior of each module is 5.7m x 2.0m. Together, the four modules create the space needed to develop the requested WC and shower areas within the final agreed room plan.
Doors and windows
Module 1 forms the north side of the configuration. Its exposed north wall has a single glazed door positioned between two small windows. The east and west end walls each have one high-level, top-only window.
Modules 2 and 3 each have a high-level, top-only window in both their east and west end walls. Module 4 has the same high-level window arrangement on its east and west ends, plus a further high-level, top-only window in the exposed south wall. The final internal arrangement should coordinate the requested sanitary spaces with these stored openings.
Anthracite external finish
Smooth plank cladding in Antrasit (Anthracite), reference AR16016, is selected between the frame on the exposed external walls. These comprise the north, east and west walls of Module 1; the east and west walls of Modules 2 and 3; and the east, south and west walls of Module 4.
The building has a flat roof with an approximately 120mm steel-frame fascia. No additional fascia is included in this configuration. Final fixture, material and finish details are confirmed by quotation.
Requested WC and shower fit-out
The stored design requests a WC and shower fit-out, with the precise number, position and arrangement of sanitary spaces to be confirmed in the final layout. Toilet and shower rooms require hygienic wall panels and wet-room PVC flooring to provide suitable internal surfaces for those areas.
Elsewhere, the included internal wall finish is white, lightly ribbed insulated sandwich panelling. Plasterboard and alternative hygienic-panel styles can be selected as upgrades or choices. Room-by-room flooring outside the wet areas also remains selectable rather than being fixed by this configuration. Further information on this type of facility is available under toilet and shower blocks.
Estimate, transport and siting
The indicative configured estimate is £54,000 excluding VAT, or £64,800 including VAT, subject to quotation. Transport is priced separately according to the delivery postcode and site access. Offloading or cranage, groundworks and other site-specific works are also separate from the configured estimate.
Siting is subject to a survey of the proposed location, including access and relevant site conditions. The sanitary layout, selected upgrades and final specification can be reviewed through the building configurator before quotation.
Full specification
4 P600 modules (single storey), wide layout, 5.9m x 8.8m footprint, approx 46 m2 internal usable floor area. Each module is 2.40m externally with a 2.16m internal ceiling; its approximate usable interior is 5.7m x 2.0m. Exterior: Smooth plank (AR16016) applied to exposed walls between the frame in Antrasit (Anthracite). Roof: flat roof with approximately 120mm steel-frame fascia (no extra fascia). Selected outside walls: Module 1 North wall: Full-wall cladding, Antrasit (Anthracite), Smooth plank (AR16016); Module 1 East wall: Full-wall cladding, Antrasit (Anthracite), Smooth plank (AR16016); Module 1 West wall: Full-wall cladding, Antrasit (Anthracite), Smooth plank (AR16016); Module 2 East wall: Full-wall cladding, Antrasit (Anthracite), Smooth plank (AR16016); Module 2 West wall: Full-wall cladding, Antrasit (Anthracite), Smooth plank (AR16016); Module 3 East wall: Full-wall cladding, Antrasit (Anthracite), Smooth plank (AR16016); Module 3 West wall: Full-wall cladding, Antrasit (Anthracite), Smooth plank (AR16016); Module 4 East wall: Full-wall cladding, Antrasit (Anthracite), Smooth plank (AR16016); Module 4 South wall: Full-wall cladding, Antrasit (Anthracite), Smooth plank (AR16016); Module 4 West wall: Full-wall cladding, Antrasit (Anthracite), Smooth plank (AR16016). Cladding prices are quote-only and must not be itemised in public copy. Module 1 P600 (ground floor) exposed walls — north (5.9m side): Small window + Glazed door (single) + Small window; east (2.2m end): Top-only window (high level); west (2.2m end): Top-only window (high level). Module 2 P600 (ground floor) exposed walls — east (2.2m end): Top-only window (high level); west (2.2m end): Top-only window (high level). Module 3 P600 (ground floor) exposed walls — east (2.2m end): Top-only window (high level); west (2.2m end): Top-only window (high level). Module 4 P600 (ground floor) exposed walls — east (2.2m end): Top-only window (high level); south (5.9m side): Top-only window (high level); west (2.2m end): Top-only window (high level). Requested fit-out to confirm in the final layout: WC, shower. Toilet/shower rooms require hygienic wall panels and wet-room PVC flooring; elsewhere white lightly ribbed insulated sandwich panels are the included wall finish. Plasterboard, other hygienic-panel styles and room-by-room flooring are selectable upgrades/choices, not included claims unless specified.
