Modular Classrooms
4-Module Modular Classroom with Kitchenette and WC
This single-storey modular classroom combines four P600 modules in a wide 5.9m x 8.8m configuration. It is designed for primary and secondary schools seeking additional teaching capacity, with a kitchenette and WC requested for the final layout.
£58,200ex VAT
£69,840 inc VAT · indicative configured estimate, subject to quotation. Transport depends on postcode and access; offloading, groundworks and site-specific works are separate.
Made to order. Build and delivery timing will be confirmed with your quotation.
Order the standard specification online. We'll confirm delivery, access and final order details before accepting your order and issuing your invoice.
Built to order in approx. 7–8 weeks, then delivery typically within 1–2 weeks. Delivery is priced by postcode and confirmed with your quote.
- Modules
- 4
- Storeys
- 1
- Approx. usable internal area
- 45.6 m² before partitions
- External dimensions
- 5.9m x 8.8m footprint
Design highlights
- Four connected P600 modules in a wide layout
- Single-storey 5.9m x 8.8m external footprint
- Approximately 45.6m² usable internal area before partitions
- Smooth Anthracite Grey RAL 7016 insulated exterior panels
- Dual-pitch apex roof
- Twelve large windows and one single glazed entrance door
- Kitchenette and WC requested for the final layout
Wide, single-storey classroom configuration
This configuration uses four P600 steel-framed modules connected side by side to create a wide, single-storey modular classroom. Each module measures 5.9m x 2.2m, producing an overall external footprint of 5.9m x 8.8m. The approximate usable internal area is 45.6m² before partitions, based on a conservative per-module allowance. A connected open layout may provide more usable space, depending on the final partition arrangement.
- Four P600 modules on one level
- 5.9m x 8.8m external footprint
- Approximately 45.6m² usable internal area before partitions
- Approximate usable interior per module: 5.7m x 2.0m
- 2.40m external module height and 2.16m internal ceiling
Designed for the Education sector, the building can support primary or secondary schools expanding classroom capacity. Further information about this type of space is available on the modular classrooms page.
Windows and entrance arrangement
The exposed north wall of Module 1 contains two large windows with a single glazed door positioned between them. Its east and west end walls each contain one large window. Modules 2 and 3 each have one large window in both their east and west end walls. Module 4 also has large windows in its east and west end walls, while its exposed south wall contains two further large windows. This is the stored opening arrangement for the four-module configuration.
Anthracite Grey exterior and apex roof
The selected outside walls use smooth, standard insulated sandwich panels in Anthracite Grey, RAL 7016. These panels are specified across the exposed north, east, west and south walls identified in the configuration. Above the modules, a dual-pitch apex roof completes the external design. Final fixture, junction and finish details remain subject to the quotation.
Requested kitchenette and WC fit-out
A kitchenette and WC are requested, with their final positions and associated partitions to be confirmed in the completed room layout. Bathroom walls use 40mm waterproof insulated sandwich panels as standard, while hygienic panels are available as an optional selection. Plaster applies outside bathroom walls where that finish is selected. Wet-room PVC flooring is used for shower rooms, although no shower room is included in this stored configuration.
Elsewhere, insulated sandwich panels are the included internal wall finish. Any alternative wall or floor finishes depend on the final room plan and selections confirmed in the quotation. The arrangement can be reviewed through the building configurator, but the quoted specification determines the final details supplied.
Estimate, transport and site requirements
The indicative configured estimate is £58,200 ex VAT, or £69,840 inc VAT, subject to quotation. Transport is priced separately according to the destination postcode and site access. Offloading or cranage, groundworks and other site-specific works are also separate. Siting is subject to a site survey, including access, ground conditions and the requirements of the selected location.
Full specification
4 P600 modules (single storey), wide layout, 5.9m x 8.8m footprint, approx 45.6 m2 usable internal area before partitions (conservative per-module allowance; connected open layouts may provide more space). Each module is 2.40m externally with a 2.16m internal ceiling; its approximate usable interior is 5.7m x 2.0m. Exterior: included vertical insulated sandwich panels in Anthracite Grey (RAL 7016). Roof: dual-pitch (apex) roof. Selected outside walls: Module 1 North wall: Standard insulated panel, Anthracite Grey (RAL 7016), Smooth; Module 1 East wall: Standard insulated panel, Anthracite Grey (RAL 7016), Smooth; Module 1 West wall: Standard insulated panel, Anthracite Grey (RAL 7016), Smooth; Module 2 East wall: Standard insulated panel, Anthracite Grey (RAL 7016), Smooth; Module 2 West wall: Standard insulated panel, Anthracite Grey (RAL 7016), Smooth; Module 3 East wall: Standard insulated panel, Anthracite Grey (RAL 7016), Smooth; Module 3 West wall: Standard insulated panel, Anthracite Grey (RAL 7016), Smooth; Module 4 East wall: Standard insulated panel, Anthracite Grey (RAL 7016), Smooth; Module 4 South wall: Standard insulated panel, Anthracite Grey (RAL 7016), Smooth; Module 4 West wall: Standard insulated panel, Anthracite Grey (RAL 7016), Smooth. Cladding prices are quote-only and must not be itemised in public copy. Module 1 P600 (ground floor) exposed walls — north (5.9m side): Large window + Glazed door (single) + Large window; east (2.2m end): Large window; west (2.2m end): Large window. Module 2 P600 (ground floor) exposed walls — east (2.2m end): Large window; west (2.2m end): Large window. Module 3 P600 (ground floor) exposed walls — east (2.2m end): Large window; west (2.2m end): Large window. Module 4 P600 (ground floor) exposed walls — east (2.2m end): Large window; south (5.9m side): Large window + Large window; west (2.2m end): Large window. Requested fit-out to confirm in the final layout: kitchenette, WC. Bathroom walls use 40mm waterproof insulated sandwich panels as standard, with hygienic panels optional; shower rooms use wet-room PVC flooring. Plaster applies outside bathroom walls when selected. Elsewhere insulated sandwich panels are the included wall finish; other finishes are selected for the final room layout.
