Toilet & Shower Blocks
3-Module Toilet and Shower Block
This single-storey toilet and shower block combines three P600 modules in a grid layout, providing approximately 34 m² of usable internal floor area. It suits holiday parks, campsites and large construction sites requiring dedicated WC and shower facilities.
£41,100ex VAT
£49,320 inc VAT · indicative configured estimate, subject to quotation. Transport depends on postcode and access; offloading, groundworks and site-specific works are separate.
Made to order. Build and delivery timing will be confirmed with your quotation.
Order the standard specification online. We'll confirm delivery, access and final order details before accepting your order and issuing your invoice.
Built to order in approx. 7–8 weeks, then delivery typically within 1–2 weeks. Delivery is priced by postcode and confirmed with your quote.
- Modules
- 3
- Storeys
- 1
- Floor area
- 34 m²
- Footprint
- 11.8m x 4.4m footprint
Design highlights
- Three P600 modules in a single-storey grid layout
- 11.8m x 4.4m overall footprint
- Approximately 34 m² usable internal floor area
- Single glazed entrance door with small windows
- High-level top-only windows across exposed walls
- Grey vertical ARLINE AR16016 grooved plank cladding
- Requested WC and shower fit-out to be confirmed
Configuration and dimensions
This stored configuration uses three P600 steel-framed modules arranged in a single-storey grid layout. Together, they form an overall footprint of 11.8m x 4.4m and provide approximately 34 m² of usable internal floor area. Each module measures 5.9m x 2.2m, with an approximate usable interior of 5.7m x 2.0m. The modules are 2.40m high externally and have a 2.16m internal ceiling height.
The configuration is intended as a toilet and shower block for the Construction sector, as well as holiday parks and campsites. Its three-module arrangement provides space for the requested WC and shower facilities, subject to confirmation of the final room layout, sanitary fixtures and service requirements in the quotation.
Windows and entrance
Module 1 provides the main entrance on its exposed north wall. This elevation has a single glazed door positioned between two small windows. Its exposed west end has one high-level, top-only window.
Module 2 has two high-level, top-only windows on the exposed north wall, one on the exposed east end and two on the exposed south wall. Module 3 has one high-level, top-only window on its exposed east end, two on its exposed south wall and one on its exposed west end. These are the openings stored for this configuration; final details remain subject to the confirmed quotation.
Selected external treatment
The exposed external walls are finished between the frame with Grey ARLINE AR16016 grooved plank cladding laid as vertical boards. This full-wall treatment is selected for the north and west walls of Module 1; the north, east and south walls of Module 2; and the east, south and west walls of Module 3.
The building has a flat roof with an approximately 120mm steel-frame fascia. No additional fascia is specified. The selected cladding is included within the configured estimate but is not separately itemised in public pricing.
Requested internal fit-out
A WC and shower are requested, with their positions and final arrangement to be confirmed during layout development. Toilet and shower rooms require hygienic wall panels and wet-room PVC flooring. Elsewhere, the included internal wall finish is white, lightly ribbed insulated sandwich panelling.
Plasterboard, alternative hygienic-panel styles and room-by-room flooring selections can be considered as choices or upgrades. They are not included specifications for this stored design unless they are expressly confirmed in the final quotation. Further information about this type of accommodation is available under Toilet & Shower Blocks, while configuration choices can be reviewed through the building configurator.
Price, transport and siting
The indicative configured estimate is £41,100 excluding VAT, or £49,320 including VAT, subject to quotation and confirmation of the fit-out. Transport is priced according to the delivery postcode and site access. Offloading or cranage, groundworks and other site-specific works are separate.
Final siting is subject to survey and assessment of access, levels, ground conditions, service connections and operating requirements. The quotation will confirm the final internal layout, finishes, fixtures, transport requirements and any site-specific provisions.
Full specification
3 P600 modules (single storey), grid layout, 11.8m x 4.4m footprint, approx 34 m2 internal usable floor area. Each module is 2.40m externally with a 2.16m internal ceiling; its approximate usable interior is 5.7m x 2.0m. Exterior: ARLINE AR16016 grooved plank applied to exposed walls between the frame in Grey. Roof: flat roof with approximately 120mm steel-frame fascia (no extra fascia). Selected outside walls: Module 1 North wall: Full-wall cladding, Grey, ARLINE AR16016 grooved plank, vertical boards; Module 1 West wall: Full-wall cladding, Grey, ARLINE AR16016 grooved plank, vertical boards; Module 2 North wall: Full-wall cladding, Grey, ARLINE AR16016 grooved plank, vertical boards; Module 2 East wall: Full-wall cladding, Grey, ARLINE AR16016 grooved plank, vertical boards; Module 2 South wall: Full-wall cladding, Grey, ARLINE AR16016 grooved plank, vertical boards; Module 3 East wall: Full-wall cladding, Grey, ARLINE AR16016 grooved plank, vertical boards; Module 3 South wall: Full-wall cladding, Grey, ARLINE AR16016 grooved plank, vertical boards; Module 3 West wall: Full-wall cladding, Grey, ARLINE AR16016 grooved plank, vertical boards. Cladding prices are quote-only and must not be itemised in public copy. Module 1 P600 (ground floor) exposed walls — north (5.9m side): Small window + Glazed door (single) + Small window; west (2.2m end): Top-only window (high level). Module 2 P600 (ground floor) exposed walls — north (5.9m side): Top-only window (high level) + Top-only window (high level); east (2.2m end): Top-only window (high level); south (5.9m side): Top-only window (high level) + Top-only window (high level). Module 3 P600 (ground floor) exposed walls — east (2.2m end): Top-only window (high level); south (5.9m side): Top-only window (high level) + Top-only window (high level); west (2.2m end): Top-only window (high level). Requested fit-out to confirm in the final layout: WC, shower. Toilet/shower rooms require hygienic wall panels and wet-room PVC flooring; elsewhere white lightly ribbed insulated sandwich panels are the included wall finish. Plasterboard, other hygienic-panel styles and room-by-room flooring are selectable upgrades/choices, not included claims unless specified.
